Description
A good 5g modem router cpe
Product main features
Using MT7981B solution, ARM Cortex-A53 dual-core CPU, main frequency up to 1.3GHZ;
Adopt independent WIFI6 chip, MT7976CN, the speed is up to 3000Mbps;
High-speed 1GB DDR4, with 128MB SPI NAND Flash;
1WAN+4LAN 1000M adaptive network port, support automatic flip (Auto MDI/MDIX);
Support “one-key flashing mode”, that is, long press the reset button to enter the rescue flashing mode;
Support “one key ” MESH network;
Built-in 2 M.2/Mini-PCIE standard interfaces (choose one of the two), which can be used to connect to 5G/4G mobile communication modules;
External standard Nano SIM card (small card) interface and built-in eSIM (QFN-8 6mmx5mm) card interface, support SIM/USIM card;
External high-gain WIFI antenna, 360-degree wireless signal without dead angle
Hardware Interface
| Network ports | 1*WAN port, 1000Mbps supports automatic flip (Auto MDI/MDIX)
Conforms to IEEE 802.3/802.3u/802.ab |
|
| 4* LAN port, 1000Mbps supports automatic flip (Auto MDI/MDIX)
Conforms to IEEE 802.3/802.3u/802.ab |
||
| Power interface | DC5.5*2.1MM | |
| Button | 1 Reset button,1*USB3.0 port,1* MESH button. | |
| 4G/5G interface | 2 *M.2 Ports | |
| Un-removable Antennas | 5G dual module | 2* external omnidirectional 5dbi 5G mobile communication & 2.4G Wifi dual frequency dual outlet antennas |
| 2* external omnidirectional 5dbi 5G mobile communication & 5.8G WIFI dual frequency dual outlet antennas | ||
| 4* external omnidirectional 5dbi 5G mobile communication single outlet antennas | ||
| 1* internal omnidirectional 5dbi 5.8G WIFI FPC antenna | ||
Hardware Platform
| Processor | MT7981B ARM Cortex-A53 dual-core CPU, 1.3GHZ main frequency |
| WIFI Chip | MT7976CN IEEE 802.11n/g/b/a/ac/ax,Max. 3000Mbps |
| RAM | DDR4 1GB |
| Flash | Nor Flash 16MB(Optional) |
| SPI NAND Flash 128MB | |
| EMMC 8GB (Optional) |
