Description
4G lte wifi router for bus 2.4g 5.8g dual band
Brief Introduction
Dual band 3G/4G WiFi router (3G / 4G gateway) specially for Vehicle use.
1 WAN,1 LAN, support 802.11 a/b/g/n/a/ac and 3G /4G.
This device has Wide Area Network VPN tunnel, Local Area Network WiFi security authentication, 4G / 3G / and watchdog functions etc., to achieve wireless LAN and wireless WAN seamless connection, automatic network redial to provide users with high-speed, secure, reliable mobile broadband services, while supporting 4G / 3G SIM card of Mobile, China Unicom and also Provides a USB 2.0 data interface, a MICRO SD (TF) card interface, with larger storage function.
This device is with metal case and vehicle anti-interference design, to achieve excellent anti-interference performance.
Also it uses vehicle power supply design, support 9V~28V Car power supply,can effectively prevent equipment damage from vehicles’ power fluctuations, it offers a wonderful solution for vehicle WiFi such as bus WiFi,car WiFi, train WiFi, taxi WiFi etc.
This device also widely used in WIFI coverage project like Bus station, the Airport, Sea port etc. At the same time, it is also widely used in scenic where WIFI coverage and other public places where WIFI coverage of the Internet.
Feature
Special for Vehicle use;
Complies with 802.11b / g / n / a / ac. wireless protocol;
Wireless Rate up to 1200Mbps;
Support 4G / 3G watchdog function, automatic network redial.
Can be dialed through an external USB interface (need to mount USB 3G, 4G network card)
Support GPS function (depending on 3,4g module)
Support to automotive power 12V and 24V systems, the minimum operating voltage is 9V, the maximum operating voltage is 28V. The maximum can be withstand 174V duration 150ms surge voltage, meet to 5a, 5b standard of the car protection.
Specification
| Hardware | |
| Main Chipset | MT7620A+7612E/580Mhz |
| RAM | DDR2 128MB （Max 256MB） |
| FLASH | 16MB （Max 16MB） |
| Antenna | 7 external 5dbi OMNI antennas (4 for wifi antennas, 2 for 3/4g module antenna, 1 for GPS antenna, the details need according to customer requirements) |
| Interface | 1* 10/100M Auto MDI/MDIX WAN |
| Button | Reset |
| LED | Power,WLAN,LAN,3G/4G,USB,5G., |
| Power | Input 12V 1A |
| Dissipation | ≦ 15W |
| Product Size | 125.5*100.5*25mm |
| Wireless | |
| Protocol Standard | IEEE 802.11n、IEEE 802.11g、IEEE 802.11b; |
| Wireless Rate | 2.4GHz，Up to 300Mbps,5.8GHz, Up to 900Mbps |
| Work Frequency | 2.4G:2412 MHz-2484MHz(channel 1 -channel 14),
5.8G: 5725MHZ-5850M(channel:：149、153、157、161、165) |
| RF Output Power | 802.11n 17±1dBm;802.11g 17±1dBm;802.11b 19±1dBm;u802.11n 15dBm±2dBm 802.11a 20dBm±2dBm 802.11ac 20dBm±2dBm |
| Receive sensitivity | 802.11b ≦-76dBm;802.11g ≦-65dBm |
| 802.11n(20M) ≦-62dBm;802.11n(40M) ≦-55dBm | |
| 802.11a ≦-64dBm，802.11ac ≦-59dBm | |
| PPM | ±10 |
| Distance | 50 Meters |
| QTY of current users | 64 |
| Wi-Fi security | 64/128/152 WEP |
| WPA-PSK/WPA2-PSK,WPA/WPA2 Security system | |
| Software | |
| Firmware | MTK SDK;OPENWRT. |
| WAN | PPPoE, Dynamic IP, Statics IP |
| DHCP | DHCP server; Client table; Statics IP; |
| Virtual Server | Port transfer and store DMZ |
| Security | Client Filter Mac Filter URL Filter Remote Website Management |
| DDNS | Support |
| QOS | Support |
| Statics IP | Support |
| Sys Log | Support |
| Style Change | Support |
| Others | |
| Work Environments | Operating Temperature：0℃ ~ 40℃； Storage Temperature：-40℃~ 70℃； Operating Humidity：10%~90% non-condensing |
Check another single band 2.4g wifi bus router below
